Adastra RMD Series 100V 4 Zone Mixer Amplifier with DAB+, BT, USB/SD

5-channel 19" rack-mountable mixer-amplifier, tailored to commercial sound installations to power 100V line speakers or standard speakers down to a 4 Ohm load. Input options include XLR (with switchable phantom power), mic/line jack, and RCA line.

Features an inbuilt DAB+/FM radio tuner, front-mounted SD/USB ports, and Bluetooth® connectivity, all controlled via an integrated media player for hassle-free playback.

A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1, and rear panel 24V contacts can mute all except mic input 1 when triggered.

Outputs on screw terminal are via 4 switchable zones with a separate "always on" output for priority alert speakers.

FEATURES

• DAB+/FM radio tuner
• Bluetooth receiver with unique serial ID
• USB/SD audio player
• 4 switchable 100V outputs and 1 un-switched output
• Optional 4-16 Ohm output
• XLR input with switchable +20V phantom power
• 2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output
• Switchable VOX voiceover feature
• 2U 19" rack mountable (rack ears supplied)
• 24V emergency mute contacts
• Mains 230Vac or 24Vdc power option

Note: Power output varies depending on model selected

• Weight: 4.98 kg
• Dimensions (W x H x D): 433 x 320 x 88 mm
• Fuse: T2A
• Output Power (RMS): 60W
• Power Supply: 170-264Vac, 50Hz (IEC)
• DC Power: 24Vdc (screw terminals)
• Inputs: Mic XLR, 2 x mic/line jack, 2 x RCA line
• Input Sensitivity (Mic 1 - Balanced): -53dBV
• Input Impedance (Mic 1): 5kΩ
• Input Sensitivity (Line - Unbalanced): -15dBV (-18.5dBV Line 5)
• Input Impedance (Inputs 2-5): 1kΩ
• Line Output: RCA
• Speaker Outputs: 4 switched + 1 non-switched 100V / 4-16Ω / COM
• Bluetooth Version: 5.0
• Controls: Mic1, mic/line2+3, line4+5, bass, treble, master volume
• Equaliser (Bass): 100Hz ±10dB
• Equaliser (Treble): 10kHz ±10dB
• Rear Panel Switches: Phantom, Vox, Mic/Line (2 + 3)
• Phantom Power: +20V (Mic 1 XLR, switchable)
• Audio Source: DAB+/FM tuner, USB/SD player, Bluetooth receiver
• Emergency Control: 24V contacts - mute all except Mic 1 when triggered
• Total Harmonic Distortion (THD): <1.0%

• 1 x RM-series 100V mixer-amplifier

• 1 x Rack-mounting ears & hardware

• 1 x IEC power lead(s)

• User Manual
