Systemline E50 Bedroom + En-Suite Bluetooth Ceiling Speaker System

The Systemline E50 Bedroom + En-Suite is the perfect system for music throughout your bedroom and into your en-suite.

Featuring a discreet wall mounted speaker selector switch that allows you to switch between the bedroom, the en-suite or both rooms together at the same time.

Our dual zone system bundles are designed to keep costs down and usability high in situations where you’d want the same music to play at the same time.

FEATURES

• BLUETOOTH: Pair your smartphone and stream your favourite music wirelessly from your smartphone, tablet or computer including YouTube, Spotify, TuneIN radio and much more.


• WALL KEYPAD: From the stylish gloss black or white wall mounted keypad you can easily adjust the volume, play, pause and skip tracks.


• WIRELESS: Once you connect your phone the system automatically turns itself on and springs into life with your favourite music.


• AUX INPUT: There’s a rear mounted AUX input for connecting to your TV or other analog audio device. The black panel also features a front mounted AUX input (not available on the white version)


• WORKS WITH ALEXA: Pair the Systemline E50 to an Amazon Echo device via Bluetooth for full voice control of your music.

Note: This is a dual zone bundle designed to play your music at the same time and same volume across both zones. You can turn each individual room on, off or both rooms on together but both areas will play the same music at the same volume.

SPEAKER CHOICE

The Q Acoustics E120 is available with standard or high definition in ceiling speakers.

Both speakers are great quality and offer a great sound, but the high definition speakers are a significant upgrade to the standard and if you heard them side by side there is a night and day difference.

STANDARD

The standard speakers included with the Q Acoustics E120 are the Q Acoustics Install QI65CB.

At 6.5" these are capable background music ceiling speakers designed to offer good sound quality at a low cost.

These are ideal for general background music.

HIGH DEFINITION

If you're looking for better sound quality then we'd suggest upgrading to the high definition IC6 speakers.

These are a night and day difference to the QI65CB, these are a much higher end ceiling speaker with a significantly improved frequency response, power handling and crossover.

In English that means you get a lot more bass and a much clearer, crisper sound quality.

The high def speakers are perfect where sound quality is important as they really do sound significantly better without costing a fortune.

You can clearly "hear" the difference just by looking at the comparison picture.

AMPLIFIER

• Dimensions: 150 x 90mm x 47mm (WxHxD)
• Inputs: Front & Rear Line In 3.5mm Stereo Jack (Audio In), DC Jack (18V DC In)
• Outputs: Speaker x 2 (Up to 4 8ohm speakers)
• Amplifier: 18W Per Channel
• Dimensions: (WxHxD) 50mm x 82mm x 68mm
• Plug Type: UK 3 Pin
• Inputs: 110-240VAC 50-60Hz 1.6A
• Outputs: 18V 2.8A

SPEAKERS (STANDARD)

Brand = Q Acoustics

Model = QI65CB

• Woofer diameter: 6.5"
• Cutout size: 203mm
• Power handling (program): 50W
• Impedance (nominal) ohms: 8ohm
• Sensitivity dB spl (2.83V, 1m): 93
• Response(Low freq.) -3dB Hz: 77 - 20,000
• Maximum rear depth: 79mm
• Size(Round grilles): 232mm dia
• Warranty: 5 Years

SPEAKERS (HIGH DEFINITION)

Brand = Q Acoustics

Model = QI65C

• Tweeter: Swivel
• Tweeter diameter: 0.75" (19mm)
• Woofer diameter: 6.5"
• Cutout Size: 203mm
• Power handling (program): 15-60W
• Impedance (nominal) ohms: 8ohm
• Sensitivity dB spl (2.83V, 1m): 89
• Response(Low freq.) -3dB Hz: 75
• Maximum rear depth: 79mm
• Size(Round grilles): 232mm dia
• Warranty: 5 Years

SPEAKER (BATHROOM)

Brand = Q Acoustics

Model = QI65CW-ST

• Tweeter: Swivel
• Tweeter diameter: 2 x 0.5" (13mm)
• Woofer diameter: 6.5"
• Power handling (program): 15-60W
• Impedance (nominal) ohms: 8 ohm
• Sensitivity dB spl (2.83V, 1m): 85
• Response(Low freq.) -3dB Hz: 65
• Maximum rear depth: 84mm
• Size(Round grilles): 232mm dia
• Warranty: 5 Years

• 1 x Systemline E50 In Wall Amplifier
• 2 x 6.5" In Ceiling Speakers
• 1 x 6.5" Stereo Bathroom Ceiling Speaker
• 1 x QED WM17 In Wall Selector Switch
• 20m x Speaker Cable

• Systemline E50 User Guide
• Systemline E50 Wiring Guide
• Installation Manual
• E50 User Manual
• E Series with 4 speakers
• E50 Pairing with echo Dot - Alexa
• E50 User Guide Videos
